Frames

Image Type Order code Description Packages
01 1721F85-916 2TK A0 0 0 0 4 815 Cover frame for 1-gang cover plated accessories, 85 mm 10/100
02 1722F85-916 2TK A0 0 0 0 4 816 Cover frame for 2-gang cover plated accessories, 85 mm 5/50
03 1723F85-916 2TK A0 0 0 0 4 817 Cover frame for 3-gang cover plated accessories, 85 mm 5/50
04 1724F85-916 2TK A0 0 0 0 4 818 Cover frame for 4-gang cover plated accessories, 85 mm 5/25
05 1725F85-916 2TK A0 0 0 0 4 819 Cover frame for 5-gang cover plated accessories, 85 mm 5/25
06 1721F100-916 2TKA00004820 Cover frame for 1-gang cover plated accessories, 100 mm 10/100
07 1722F100-916 2TK A0 0 0 0 4 871 Cover frame for 2-gang cover plated accessories, 100 mm 5/50
08 1723F100-916 2TKA00004872 Cover frame for 3-gang cover plated accessories, 100 mm 5/50
09 1724F100-916 2TKA00004873 Cover frame for 4-gang cover plated accessories, 100 mm 5/25
10 1725F100-916 2TK A0 0 0 0 4 874 Cover frame for 5-gang cover plated accessories, 100 mm 5/25

——— —— ——— ——
01 02 03 04 05 06 07 08 09 10

—
Other accessories

Image Type Order code Description Packages
01 2538-916 2TKA00004884
02 2538-100-916 2TKA00004885 Center plate Without imprint Switch/push button, 85 mm 10/100
03 2519-916 2TKA00004883
04 1746-916-101-510 2CK A0 01726A0239 Center plate Without imprint Switch/push button, 100 mm 10/100
05 2518-WD-916 2TKA00005250
Adapter 1-gang(s) 20/200

For multimedia inserts RJ1 with cover plate 50x50 mm 1/10

Cover frame for 1-gang devices, IP44 1/10

— — — ——
