Smart boxes


AU80 -range
AU80 -range is desiged to be used with flexible conduit, 6 pcs 16mm knock-outs and 2 pcs 20mm knock-outs.
With use of red distance ring the box will always stay on the plaster wall level. With two plaster boards (24 mm) the
distance ring will be removed.

Type EAN Description Package
AU80 6438199004266 Mounting box 80
AU80.2 6438199004273 Mounting box with truss fixture 60
AU81 6438199004839 Mounting box for flat socket outlet 30
AU81.2 6438199004846 Mounting box for flat socket outlet 25

Interconnector Nordic Box
Interconnector AS8.3 is used when low-voltage or strong-current circuit box groups are installed under different
cover plates. With interconnector AS8.3 the distance between box centers are either 85 mm or 100 mm depending
on installation. Additionally, AS8.3 can be used as a inlet for 20 mm flexible conduit with AU80 -range boxes. Made of
halogen free material (IEC/61249-2-21).

Type EAN Description Package
AS8.3 6438199005133 Interconnector C/C 85 mm and C/C 100 mm 50/250

Quadruple inlet for flexipipe
Quadruple inlet for AU80 -range installation boxes, with locking device for flexible conduit. Can be used with two
Ø16 mm and with additional two Ø16/20 mm flexipipe (20 mm inlets are equipped with reducer to Ø16 mm and with
plugs). To be installed to the side of the installation box where there are two Ø20 mm knock-outs. IP rating IP3X.
Made of halogen free material (IEC/61249-2-21).

Type EAN Description Package
AN8.4 6438199005140 Quadruple inlet for flexipipe, 2 x Ø16 mm + 2 x Ø16/20 mm 20/100

Mounting box support
Mounting box supports are used to fit the blue mounting boxes AU5.5, AU60.1 and AU60.5 between two boards in
hollow walls. Made of halogen free material (IEC/61249-2-21).

Type EAN Description Package
AS27 6418677329890 Box support, 25 mm 50
AS27.12 6418677332425 Box support, 12 mm 50
