Flush mounting 2-pole switch, IP21
Switches with screwless terminals and rocker with clip-on fastening. The terminals are for max 2 rigid wires. Flush
mounting on a smooth surface IP21.

Type         EAN                       Description                                                         Package

Includes switch insert and rocker                                                                               1/10

1062UC-84    6438199001180 2-pole 1-gang 1-way switch, 16AX/250 V, Impressivo, 2 X-terminals,                10/100
                                         white                                                                  1/10
                                                                                                                1/10
Modular
                                                                                                                1/10
1062.21      6418677328633 Switch insert, 16AX/250 V, 2-pole, 2 X-terminals, lamp possibility                        1
                                                                                                                     1
1788-81      6418677328954 Switch rocker, Impressivo, 1-gang, red lens, "1/0" symbol, anthracite

1788-83      6418677328961 Switch rocker, Impressivo, 1-gang, red lens, "1/0" symbol, aluminum

Design series. Delivery time 3 weeks.

1788-866     4011395086322 Switch rocker, 1-gang, red lens, "1/0" symbol, steel

1788-884     4011395129319 Switch rocker, 1-gang, red lens, "1/0" symbol, white matt

1788-885     4011395129760 Switch rocker, 1-gang, red lens, "1/0" symbol, black matt

Lamps for switches
Lamps for switches and push buttons. Lamps can be installed in 1-gang switch inserts that include the signal-/
search light possibility. Lamps can't be installed in 2- or 3-gang switch inserts.

Type         EAN                       Description                                                         Package
8370         6410021060701             Lamp, 230 V/0.4 mA, fluorescent, for 1-gang switches                  10/100
8372         6410021060725             Lamp, 230 V/2 mA, fluorescent, for 1-gang switches                    10/100
8375         6410021060756             Lamp, 24 V/22 mA, incandescent, for 1-gang switches                   10/100
8376         6410021060763             Lamp, 12 V/40 mA, incandescent, for 1-gang switches                   10/100
8370R        6438199004860             Lamp, 250 V/0.4 mA, LED, for 1-gang switches                          10/100
8375R        6438199004877             Lamp, 5-24 V/0.5-2.5 mA, LED, for 1-gang switches                     10/100

Flush mounting 2-gang switches, IP21
Switches with screwless terminals and rocker with clip-on fastening. The terminals are for max 2 rigid wires. Flush
mounting on a smooth surface IP21.

Type         EAN                       Description                                                         Package

Includes switch insert and rocker                                                                               1/10
                                                                                                                1/10
1065UC-84    6438199001241 2-gang 1-way switch, 16AX/250 V, Impressivo, 2 X-terminals, white
                                                                                                             10/100
10666UC-84   6438199001272 2-gang 2-way switch, 16AX/250 V, Impressivo, no X-terminals, white
                                                                                                             10/100
Modular
                                                                                                                1/10
1065.20      6418677328756 2-gang 1-way switch insert, 16AX/250 V, 2 X-terminals, no lamp                       1/10
                                         possibility                                                            1/10

10666.00     6418677328763 2-gang 2-way switch insert, 16AX/250 V, no X-terminals, no lamp                      1/10
                                         possibility                                                                 1
                                                                                                                     1
1785-84      6418677329098 Switch rocker, Impressivo, 2-gang, white

1785-81      6418677329111 Switch rocker, Impressivo, 2-gang, anthracite

1785-83      6418677329128 Switch rocker, Impressivo, 2-gang, aluminum

Design series. Delivery time 3 weeks.

1785-866     4011395086346 Switch rocker, 2-gang, steel

1785-884     4011395129210 Switch rocker, 2-gang, white matt

1785-885     4011395129685 Switch rocker, 2-gang, black matt

Flush mounting 2-pole + 1-way switch, IP21
The switch has one 1-way switch and one 2-pole 1 switch together. Switches with screwless terminals and rocker
with clip-on fastening. The terminals are for max 2 rigid wires. Flush mounting on a smooth surface IP21.

Type         EAN                       Description                                                         Package

Includes switch insert and rocker      2-pole 2-gang 1-way switch, Impressivo, no X-terminals, white            1/10
                                       2-pole 2-gang 1-way switch, Impressivo, no X-terminals, anthracite       1/10
10621UC-84   6438199001159             2-pole 2-gang 1-way switch, Impressivo, no X-terminals, aluminum         1/10

10621UC-81   6438199001135

10621UC-83   6438199001142
