IMPRESSIVO® 13

Push button panel 4/2-gang, 5-24V ac/dc
4/2-gang push button panel to control bistable relays or electronic control systems. Load capacity 1A AC/DC. White
LED-light with adjustable illumination. Installation on surface or on top of a standard flush mounting box.

Type EAN Description Package
FAP1204-84 6438199002309 Push button, 4/2-gang, Impressivo, white 1/10
FAP1204-81 6438199002286 Push button, 4/2-gang, Impressivo, anthracite 1/10
FAP1204-83 6438199002293 Push button, 4/2-gang, Impressivo, aluminum 1/10

1-gang rockers, IP21/IP44
1-gang rockers for all 1-gang switch inserts. Flush- and surface mounting: Protection class IP21, and IP44 with a seal
and screw fastening rocker frame.

Type EAN Description Package
1/10
1786-84 6418677328855 Switch rocker, Impressivo, 1-gang, white 1/10
1/10
1786-81 6418677328879 Switch rocker, Impressivo, 1-gang, anthracite
1/10
1786-83 6418677328886 Switch rocker, Impressivo, 1-gang, aluminum 1
1
Design series. Delivery time 3 weeks.

1786-866 4011395086018 Switch rocker, 1-gang, steel

1786-884 4011395129289 Switch rocker, 1-gang, white matt

1786-885 4011395129753 Switch rocker, 1-gang, black matt

1-gang rockers with name plate, IP21/IP44
1-gang rockers for all 1-gang switch inserts. Flush- and surface mounting: Protection class IP21, and IP44 with a seal
and screw fastening rocker frame. The rockers have a name plate (59,7 mm x 11,7 mm) with a strip for writing. The
delivery includes one blank strip and one strip with the text "MASTER".

Type EAN Description Package
1764NLI-84 1/10
6418677328893 Switch rocker, Impressivo, 1-gang, nameplate, white 1/10
1/10
1764NLI-81 6418677328916 Switch rocker, Impressivo, 1-gang, nameplate, anthracite
1/10
1764NLI-83 6418677328923 Switch rocker, Impressivo, 1-gang, nameplate, aluminum 1
1
Design series. Delivery time 3 weeks.

1764NLI-866 4011395086186 Switch rocker, 1-gang, nameplate, steel

1764NLI-884 4011395131619 Switch rocker, 1-gang, nameplate, white matt

1764NLI-885 4011395128213 Switch rocker, 1-gang, nameplate, black matt

1-gang rockers with red lens, IP21/IP44
1-gang rockers for all 1-gang switch inserts. Flush- and surface mounting: Protection class IP21, and IP44 with a seal
and screw fastening rocker frame. The rockers contain a red lens.

Type EAN Description Package
1/10
1789-84 6418677328978 Switch rocker, Impressivo, 1-gang, red lens, white 1/10
1/10
1789-81 6418677328992 Switch rocker, Impressivo, 1-gang, red lens, anthracite
1/10
1789-83 6418677329005 Switch rocker, Impressivo, 1-gang, red lens, aluminum 1
1
Design series. Delivery time 3 weeks.

1789-866 4011395086063 Switch rocker, 1-gang, red lens, steel

1789-884 4011395129456 Switch rocker, 1-gang, red lens, white matt

1789-885 4011395129852 Switch rocker, 1-gang, red lens, black matt
