12 WIRING ACCESSORIES CATALOG 2019

2-gang push switch inserts
2-gang push switches with screwless terminals and rocker with clip-on fastening. The terminals are for max 2 rigid
wires. Flush mounting on a smooth surface IP21.

Type         EAN                       Description                                                         Package
Modular
                                                                                                             10/100
2020/4U-101  6418677304217 Push switch insert 10A/250V, for up/down control                                     1/10
                                                                                                                1/10
1785JA-84    6418677329135 Switch rocker, Impressivo, 2-gang, "up/down" symbol, white                           1/10

1785JA-81    6418677329159 Switch rocker, Impressivo, 2-gang, "up/down" symbol, anthracite                      1/10
                                                                                                                     1
1785JA-83    6418677329166 Switch rocker, Impressivo, 2-gang, "up/down" symbol, aluminum                             1

Design series. Delivery time 3 weeks.

1785JA-866   4011395086681 Switch rocker, 2-gang, "up/down" symbol, steel

1785JA-884   4011395129173 Switch rocker, 2-gang, "up/down" symbol, white matt

1785JA-885   4011395129531 Switch rocker, 2-gang, "up/down" symbol, black matt

Flush mounting 3-gang 1-way switch, IP21
Switches with screwless terminals and rocker with clip-on fastening. The terminals are for max 2 rigid wires. Flush
mounting on a smooth surface IP21.

Type         EAN                       Description                                                         Package

Includes switch insert and rocker      3-gang 1-way switch, 16AX/250 V, Impressivo, no X-terminals, white       1/10

10631UC-84   6438199001210             3-gang 1-way switch insert, 16AX/250 V, no X-terminals, no lamp       10/100
                                       possibility                                                              1/10
Modular                                Switch rocker, Impressivo, 3-gang, anthracite                            1/10
                                       Switch rocker, Impressivo, 3-gang, aluminum
10631.00     6418677328794

1783-81      6418677329234
1783-83      6418677329241

Flush mounting 1-gang 2-way switch, IP44
Product includes switch insert, rocker, cover frame, screw-mounted rocker frame and seal. Screwless terminals are
for max 2 rigid wires. Flush mounting on rough surface IP44.

Type         EAN                       Description                                                         Package
1066UW-84                                                                                                       1/10
             6438199000022 1-gang 2-way switch,16AX/250 V, Impressivo, no X-terminals, IP44

Flush mounting 2-gang 1-way switch, IP44
Product includes switch insert, rocker, cover frame, screw-mounted rocker frame and seal. Screwless terminals are
for max 2 rigid wires. Flush mounting on rough surface IP44.

Type         EAN                       Description                                                         Package
1065UW-84                                                                                                       1/10
             6438199000039 2-gang 1-way switch, 16AX/250 V, Impressivo, no X-terminals, IP44

Card switch
Card switch can be used, for example, as a hotel room ”main switch”. The card switch is operated with a credit card
sized card. Delivery includes a 230V lamp.

Type         EAN                       Description                                                         Package
8114.1       6438199000534
1792-84      6418677329258             Card switch insert, 16AX/250 V, 2-pole, no X terminals, lamp included 10/100
1792-81      6418677329272
1792-83      6418677329289             Center plate, Impressivo, for card switch 8114.1, white             1/10
1792-866     4011395086797
1792-884     4011395131664             Center plate, Impressivo, for card switch 8114.1, anthracite        1/10
1792-885     4011395127285
8331         6410021060909             Center plate, Impressivo, for card switch 8114.1, aluminum          1/10

                                       Center plate, for card switch 8114.1, steel                                   10

                                       Center plate, for card switch 8114.1, white matt                              1

                                       Center plate, for card switch 8114.1, black matt                              1

                                       Lamp, 230 V/1.5 mA, fluorescent, for card switch                    10/100
