1-gang rockers with transparent lens and ''light'' symbol, IP21/IP44
1-gang rockers for all 1-gang switch inserts. Flush- and surface mounting: Protection class IP21, and IP44 with a seal
and screw fastening rocker frame. The rocker contains transparent lens and "Light" symbol.

Type EAN Description Package
1/10
1789LI-84 6418677334498 Switch rocker, Impressivo, 1-gang, "light" symbol, lens, white 1/10
1/10
1789LI-81 6418677334511 Switch rocker, Impressivo, 1-gang, "light" symbol, lens, anthracite
1/10
1789LI-83 6418677334528 Switch rocker, Impressivo, 1-gang, "light" symbol, lens, aluminum 1
1
Design series. Delivery time 3 weeks.

1789LI-866 4011395086087 Switch rocker, 1-gang, "light" symbol, lens, steel

1789LI-884 4011395129418 Switch rocker, 1-gang, "light" symbol, lens, white matt

1789LI-885 4011395129821 Switch rocker, 1-gang, "light" symbol, lens, black matt

1-gang rockers with transparent lens and ''key'' symbol, IP21/IP44
1-gang rockers for all 1-gang switch inserts. Flush- and surface mounting: Protection class IP21, and IP44 with a seal
and screw fastening rocker frame. The rocker contains transparent lens and "key" symbol.

Type EAN Description Package
1/10
1789TR-84 6418677329012 Switch rocker, Impressivo, 1-gang, "key" symbol, lens, white 1/10
1/10
1789TR-81 6418677329036 Switch rocker, Impressivo, 1-gang, "key" symbol, lens, anthracite
1/10
1789TR-83 6418677329043 Switch rocker, Impressivo, 1-gang, "key" symbol, lens, aluminum 1
1
Design series. Delivery time 3 weeks.

1789TR-866 4011395086131 Switch rocker, 1-gang, "key" symbol, lens, steel

1789TR-884 4011395129432 Switch rocker, 1-gang, "key" symbol, lens, white matt

1789TR-885 4011395129838 Switch rocker, 1-gang, "key" symbol, lens, black matt

1-gang rockers with transparent lens and ''bell'' symbol, IP21/IP44
1-gang rockers for all 1-gang switch inserts. Flush- and surface mounting: Protection class IP21, and IP44 with a seal
and screw fastening rocker frame. The rocker contains transparent lens and "bell" symbol.

Type EAN Description Package
1789KL-84 1/10
6418677329050 Switch rocker, Impressivo, 1-gang, "bell" symbol, lens, white 1/10
1/10
1789KL-81 6418677329074 Switch rocker, Impressivo, 1-gang, "bell" symbol, lens, anthracite
1/10
1789KL-83 6418677329081 Switch rocker, Impressivo, 1-gang, "bell" symbol, lens, aluminum 1
1
Design series. Delivery time 3 weeks.

1789KL-866 4011395086117 Switch rocker, 1-gang, "bell" symbol, lens, steel

1789KI-884 4011395129357 Switch rocker, 1-gang, "bell" symbol, lens, white matt

1789KI-885 4011395129791 Switch rocker, 1-gang, "bell" symbol, lens, black matt

Seal for switches, IP44
Seal for 85 mm cover frame. Switches and push switches are IP21 when installed on a rough surface with a seal.
Protection class is IP44 when using screw-mounted rocker frame with a seal.

Type EAN Description Package
2463 6418677328176 Seal for 85 mm cover frame, IP44 20/200

Screw-mounted rocker frames, IP44
Screw-mounted rocker frames are used with the seals 2463 or 2464 to reach IP44 protection class on switches and
push switches. Furthermore, it can be used to connect the switch frame to the insert for improved security.

Type EAN Description Package
2474 6418677328190 Supporting frame for 1/3-gang rocker, screw fastening 20/200
2475 6418677328206 Supporting frame for 2-gang rocker, screw fastening 20/200
