IMPRESSIVO® 19

Seal for 2-gang socket outlet, IP44
2-gang socket outlets installed with a seal and a center plate with a hinged lid are IP44. Socket outlet without hinged
lid on a rough surface is IP21.

Type EAN Description Package
2464 6418677328183 Seal for 100 mm cover frame, IP44 20/200

Seal for 1-gang socket outlet, IP44
1-gang socket outlets installed with a seal and a center plate with a hinged lid are IP44. Socket outlet without hinged
lid on a rough surface is IP21.

Type EAN Description Package
2463 6418677328176 Seal for 85 mm cover frame, IP44 20/200

Claws
Claws for 1-gang socket outlets, Euro socket outlets, switches and push switches. Not suitable for 2-gang
Impressivo socket outlet inserts. Inserts with claws are also available.

Type EAN Description Package
ASE1 10/100
6410021660932 Claws for socket outlets and switches

Tele and data

RJ45 outlet with sliding dust covers for Impressivo
Insert for 2 x RJ45 connectors and center plate with dust covers. The connectors CEL30.UX are not compatible with
this device, due to its integrated blind covers.

Type EAN Description Package
Modular
1819.01 6418677330445 Supporting frame insert for 2 x RJ45, Keystone 10/100
1819.02 6418677330452 Supporting frame insert for 2 x RJ45, AMP 10/100
1819.03 6418677330469 Supporting frame insert for 2 x RJ45, Actassi 10/100
1819.04 6418677335945 Supporting frame insert for 2 x RJ45, Systimax 10/100
1819DC-84 6438199002835 Center plate, Impressivo, 2 x RJ45, dust covers, white
1819DC-81 6438199002811 Center plate, Impressivo, 2 x RJ45, dust covers, anthracite 1/10
1819DC-83 6438199002828 Center plate, Impressivo, 2 x RJ45, dust covers, aluminum 1/10
1/10

RJ45 outlet with sliding dust covers for design-series
Insert for 2 x RJ45 connectors and center plate with dust covers. The connectors CEL30.UX are not compatible with
this device, due to its integrated blind covers.

Type EAN Description Package
Modular
10/100
1810.1 6410072040639 Supporting frame insert for 2 x RJ45, green, Systimax 10/100
10/100
1812.1 6410072040837 Supporting frame insert for 2 x RJ45, red, Keystone
1/10
1814.1 6410072040851 Supporting frame insert for 2 x RJ45, black, AMP 1
1
Design series. Delivery time 3 weeks.

1800-866 4011395087923 Center plate, 2 x RJ45, dust covers, steel

1800-884 4011395127087 Center plate, 2 x RJ45, dust covers, white matt

1800-885 4011395127346 Center plate, 2 x RJ45, dust covers, black matt
