IMPRESSIVO®                                                                                            21

DKS-adapters
Different adapters for DKS-system. Suitable for DKS-center plate 1758-xx.

Type          EAN                      Description                                                     Package
RJ45
1867EB        4011395182802            Adapter for DKS-system, 2 x RJ45, Keystone                        10/100
1875EB        4011395776902            Adapter for DKS-system, 2 x RJ45, AMP                             10/100
1872EB        4011395540800            Adapter for DKS-system, 2 x RJ45, Systimax                        10/100
Fiber
1870EB        4011395454107            Adapter for DKS-system, fiber 2 x Simplex ST                      10/100
1874EB        4011395734902            Adapter for DKS-system, fiber 2 x SCD                             10/100
Audio
1853EB        4011395181409            Adapter for DKS-system, XLR audio connector type FP               10/100
1854EB        4011395181508            Adapter for DKS-system, XLR audio connector type MP               10/100
1876EB        4011395022566            Adapter for DKS-system, XLR D-type or Speakon audio connector     10/100
Others
1850EB        6438100605308            Adapter for DKS-system, D-type 9-pin connector                    10/100
1855EB        4011395181607            Adapter for DKS-system, 2 x BNC/TNC, 9,8 mm                       10/100
1857EB        6418677329975            Adapter for DKS-system, 2 x BNC/TNC, 12,9 mm                      10/100
1869EB        4011395183007            Adapter for DKS-system, blank                                     10/100

Antenna center plate
Center plate for common antenna outlet inserts. The terminal “Sat” is closed, but can be knocked out.

Type          EAN                      Description                                                     Package
1743-84       6418677329418            Center plate, Impressivo, TV/R/Sat, white                            1/10
                                                                                                            1/10
1743-81       6418677329432 Center plate, Impressivo, TV/R/Sat, anthracite                                  1/10

1743-83       6418677329449 Center plate, Impressivo, TV/R/Sat, aluminum                                    1/10
                                                                                                                 1
Design series. Delivery time 3 weeks.                                                                            1

1743-866      4011395087893 Center plate, TV/R/Sat, steel

1743-884      4011395128626 Center plate, TV/R/Sat, white matt

1743-885      4011395128695 Center plate, TV/R/Sat, black matt

USB charger
For supply and support of two mobile devices via USB-cable. With two USB A-type connectors. With electronic
short-circuit and overload protection. Rated voltage: 230 V~/5 V-, 50 Hz - 60 Hz, power dissipation 0.3W. Suitable for:
In case one output is used rated current max 1400 mA. In case two output are used rated current max 700 mA.

Type          EAN                      Description                                                     Package
Insert
                                                                                                                 1
6472U         4011395151594 Tele outlet insert, USB charging station 2 x 0.7 A
                                                                                                            1/10
Center plate                                                                                                1/10
                                                                                                            1/10
1766-84       6418677331305 Center plate, Impressivo, tele outlet, white
                                                                                                            1/10
1766-81       6418677331329 Center plate, Impressivo, tele outlet, anthracite                                    1
                                                                                                                 1
1766-83       6418677331336 Center plate, Impressivo, tele outlet, aluminum

Design series. Delivery time 3 weeks.

1766-866      4011395087848 Center plate, tele outlet, steel

1766-884      4011395131626 Center plate, tele outlet, white matt

1766-885      4011395127261 Center plate, tele outlet, black matt
