26 WIRING ACCESSORIES CATALOG 2019

Adapter 85/100 mm, IP21/IP44
1-gang center plated accessories can be mounted in 100 mm cover frames with the adapter. Final IP class of
installation is defined by the accessories.

Type     EAN                        Description                                                             Package
2519-84  6418677328213              Adapter, Impressivo, 85/100 mm, white                                        1/20
2519-81  6418677328237              Adapter, Impressivo, 85/100 mm, anthracite                                   1/20
2519-83  6418677328244              Adapter, Impressivo, 85/100 mm, aluminum                                     1/20

Labeling plate
Labeling plate for Jussi and Impressivo cover frames. Size of text area is max 12 x 52 mm.

Type     EAN                        Description                                                             Package
2752                                                                                                          10/100
         6438199000848 Labeling plate for Jussi and Impressivo cover plates.

Lamps for switches
Lamps for switches and push buttons. Lamps can be installed in 1-gang switch inserts that include the signal-/
search light possibility. Lamps can't be installed in 2- or 3-gang switch inserts.

Type     EAN                        Description                                                             Package
8370     6410021060701              Lamp, 230 V/0.4 mA, fluorescent, for 1-gang switches                      10/100
8372     6410021060725              Lamp, 230 V/2 mA, fluorescent, for 1-gang switches                        10/100
8375     6410021060756              Lamp, 24 V/22 mA, incandescent, for 1-gang switches                       10/100
8376     6410021060763              Lamp, 12V/40 mA, incandescent, for 1-gang switches                        10/100
8331     6410021060909              Lamp, 230 V/1.5 mA, fluorescent, for card switch                          10/100
8370R    6438199004860              Lamp, 250 V/0.4 mA, LED, for 1-gang switches                              10/100
8375R    6438199004877              Lamp, 5-24 V/0.5-2.5 mA, LED, for 1-gang switches                         10/100

Claws
Claws for socket outlets, switches and push switches.

Type     EAN                        Description                                                             Package
ASE1                                                                                                          10/100
         6410021660932 Claws for socket outlets and switches

Impulse spring
The impulse spring can be installed into ABB switches. The impulse spring changes the switch operation to push
switch. The impulse spring can be installed to 1, 1 + 1 + 1, 5, 6, and 6 + 6 switches. Sales package contains 10 springs.
10 pcs in sales pack.

Type     EAN                        Description                                                             Package
PJ4.10                                                                                                        10/100
         6438199004808 Impulse spring for ABB switches, 10 pcs
