IMPRESSIVO® 25

—
Accessories
IP44 sealing

Screw-mounted rocker frames, IP44
Screw-mounted rocker frame is used with the seals 2463 or 2464 to reach IP44 protection class on switches and push
switches. Furthermore, it can be used to connect the switch frame to the insert with screws for improved security.

Type EAN Description Package
2474 6418677328190 Supporting frame for 1/3-gang rocker, screw fastening 20/200
2475 6418677328206 Supporting frame for 2-gang rocker, screw fastening 20/200

Seal 85 mm, IP44
1-gang socket outlet inserts installed with the seal and a center plate with hinged lid are IP44. Switches and push
buttons installed with the seal and with the screwmounted rocker frames are IP44.

Type EAN Description Package
2463 6418677328176 Seal for 85 mm cover frame, IP44 20/200

Seal 100 mm, IP44
2-gang socket outlet inserts installed with the seal and a center plate with hinged lids are IP44. Switches, push
buttons and 1-gang socket outlets with a hinged lid are also IP44, when using the seal with adaptor 2519-xx. Screw
mounted rocker frame must be used to reach IP44 protection class.

Type EAN Description Package
2464 6418677328183 Seal for 100 mm cover frame, IP44 20/200

Accessories

Blind center plate, 85 mm
85 mm blind center plate can be used to cover an empty box. It can be used together with 85 mm flush- and surface
mounting frames. Flush mounting: On a smooth surface IP21, on a rough surface IP20 (seal can't be used). When
installed on surface with 2456.26 and 172xS85-xx, protection class is IP44.

Type EAN Description Package
2538-84 6418677330551 Center plate, Impressivo, blind, white 1/10
2538-81 6418677330575 Center plate, Impressivo, blind, anthracite 1/10
2538-83 6418677330582 Center plate, Impressivo, blind, aluminum 1/10
1742-866 4011395086742 Center plate, blind, steel 1/10
1742-884 4011395126936 Center plate, blind, white matt 1
1742-885 4011395127179 Center plate, blind, black matt 1

Blind center plate, 100 mm
100 mm blind center plate can be used to cover an empty box. Can be used together with 100 mm flush- and surface
mounting frames. Flush mounting: On a smooth surface IP21, on a rough surface IP20 (seal can't be used). When
istalled on surface the protection class is IP44 if wires are installed downwards.

Type EAN Description Package
2538-100-84 6418677332319 Center plate, Impressivo, 100 mm, blind, white 1/10
2538-100-81 6418677332296 Center plate, Impressivo, 100 mm, blind, anthracite 1/10
2538-100-83 6418677332302 Center plate, Impressivo, 100 mm, blind, aluminum 1/10
