IMPRESSIVO®                                                                                                        33

2-gang Schuko socket outlet, surface mounting, IP44
Product includes Schuko socket outlet insert, center plate with lid, surface mounting cover frame and box. The
socket outlet insert has shutters and screwless terminals.

Type         EAN            Description                                                           Package
302ESW-81    6438199003443                                                                             1/10
                            Socket outlet, Impressivo IP44, 2-gang Schuko, shuttered, screwless
                            terminals, branching terminals, anthracite

2-gang Schuko outlets with special colour, IP21
Screwless terminals for each contact of the socket outlet for max 4 rigid wires. No X-terminals. The socket outlet
insert has shutters. IP21 when the wires are installed downwards. These socket outlets can be used, for instance, in
hospitals and offices, when there is a need to limit socket outlet use to certain applications.

Type         EAN            Description                                                           Package
402EA-02     6438199004723                                                                             1/10
                            Socket outlet, Impressivo, Schuko, 2-gang, shuttered, screwless
402EA-03     6438199004730  terminals, red                                                             1/10

402EA-05     6438199004747  Socket outlet, Impressivo, Schuko, 2-gang, shuttered, screwless            1/10
                            terminals, orange
402EA-06     6438199004754                                                                             1/10
                            Socket outlet, Impressivo, Schuko, 2-gang, shuttered, screwless
                            terminals, green

                            Socket outlet, Impressivo, Schuko, 2-gang, shuttered, screwless
                            terminals, blue

2-gang Schuko socket outlet, lath installation, IP21
Schuko 2-gang socket outlet for lath installation. There are screwless terminals for each contact of the socket outlet
for max 4 rigid wires. No X-terminals. The socket outlet insert has shutters.

Type         EAN            Description                                                           Package
402EL-84     6438199003894                                                                             1/10
                            Socket outlet, Impressivo, Schuko, 2-gang, shuttered, screwless
402EL-81     6438199003900  terminals, lath installation, white                                        1/10

402EL-83     6438199003917  Socket outlet, Impressivo, Schuko, 2-gang, shuttered, screwless            1/10
                            terminals, lath installation, anthracite

                            Socket outlet, Impressivo, Schuko, 2-gang, shuttered, screwless
                            terminals, lath installation, aluminium

2-gang Schuko socket outlet, corner installation, IP21
Schuko 2-gang socket outlet for corner installation. There are screwless terminals for each contact of the socket
outlet for max 4 rigid wires. No X-terminals. The socket outlet insert has shutters.

Type         EAN            Description                                                           Package
402EE-84     6438199003313                                                                             1/20
                            Socket outlet, Impressivo, Schuko, 2-gang, shuttered, screwless
402EE-81     6438199003320  terminals, corner installation, white                                      1/20

402EE-83     6438199003337  Socket outlet, Impressivo, Schuko, 2-gang, shuttered, screwless            1/20
                            terminals, corner installation, anthracite

                            Socket outlet, Impressivo, Schuko, 2-gang, shuttered, screwless
                            terminals, corner installation, aluminum

Surface mounting boxes and accessories

Surface mounting box 85 mm, IP21
Surface mounting box for 1-gang devices such as antenna and data outlet and others, insert height max. 26 mm.
Large devices such as dimmers doesn't fit in the box. Delivery includes bottom plate and cover.

Type         EAN            Description                                                           Package
1721A-84     6438199003375
1721A-81     6438199003382  Surface mounting box, Impressivo, 85 mm, h=41 mm, 1-gang, white                     1/10
1721A-83     6438199003399
                            Surface mounting box, Impressivo, 85 mm, h=41 mm, 1-gang, anthracite                1/10

                            Surface mounting box, Impressivo, 85 mm, h=41 mm, 1-gang, aluminum                  1/10
