Lath installation box 85 mm, IP21
Lath installation box for 1-gang devices such as antenna and data outlet and others, insert height max. 26 mm.
Large devices such as dimmers doesn't fit in the box. Delivery includes bottom plate and cover.

Type EAN Description Package
1721L-84 6438199003924 1/10
Surface mounting box, Impressivo, 85 mm, 1-gang, lath installation,
1721L-81 6438199003931 white 1/10

1721L-83 6438199003948 Surface mounting box, Impressivo, 85 mm, 1-gang, lath installation, 1/10
anthracite

Surface mounting box, Impressivo, 85 mm, 1-gang, lath installation,
aluminium

Corner installation box 85 mm, IP21
Surface mounting box for 2 devices, also for electronic devices. Horizontal or vertical installation in corners. Use with
85 mm 2-gang cover frame.

Type EAN Description Package
1722H-84 6438199003955 1/20
Surface mounting box, Impressivo, corner installation, 85 mm,
1722H-81 6438199003962 2-gang, white 1/20

1722H-83 6438199003979 Surface mounting box, Impressivo, corner installation, 85 mm, 1/20
2-gang, anthracite

Surface mounting box, Impressivo, corner installation, 85 mm,
2-gang, aluminium

Surface mounting bottom plate, IP21/IP44
Surface mounting bottom plate for flush mounted products, insert height max. 26 mm. To be combined with 85 mm
and 100 mm surface mounting cover frames 172xS85-xx and 172xS100-xx. Socket outlets are IP44 when using center
plates with hinged lid. Switches and push switches are IP44 when combined with screw fastening rocker. Wires must
be installed downwards for IP44 protection class. Dimmers do not fit in the box.

Type EAN Description Package
2456.26 6418677331299 Surface mounting box for flush mounted products, h=26 mm 10/100

Surface mounting cover frames 85 mm, IP21/IP44
Surface mounting cover frames for 1-gang devices, such as switches and socket outlets. Suitable for both horizontal
and vertical installation. To be used with surface mounting box 2456.26. Dimmers do not fit in the frame. Wires must
be installed downwards for IP44 protection class. Final IP class of installation is defined by the used center plate
(IP21/IP44).

Type EAN Description Package
White
1721S85-84 6418677330971 Surface mounting frame, Impressivo, 85 mm, h=40 mm, 1-gang, white 1/50
1722S85-84 6418677331015 Surface mounting frame, Impressivo, 85 mm, h=40 mm, 2-gang, white 1/25
1723S85-84 6418677331053 Surface mounting frame, Impressivo, 85 mm, h=40 mm, 3-gang, white 1/25
1724S85-84 6418677331091 Surface mounting frame, Impressivo, 85 mm, h=40 mm, 4-gang, white 1/25
Anthracite
1721S85-81 6418677330995 Surface mounting frame, Impressivo, 85 mm, h=40 mm, 1-gang, 1/50
6418677331039 anthracite 1/25
1722S85-81 6418677331077 1/25
6418677331114 Surface mounting frame, Impressivo, 85 mm, h=40 mm, 2-gang, 1/25
1723S85-81 anthracite

1724S85-81 Surface mounting frame, Impressivo, 85 mm, h=40 mm, 3-gang,
anthracite
Aluminum
1721S85-83 Surface mounting frame, Impressivo, 85 mm, h=40 mm, 4-gang,
anthracite
1722S85-83
6418677331008 Surface mounting frame, Impressivo, 85 mm, h=40 mm, 1-gang, 1/50
1723S85-83 6418677331046 aluminum 1/25
6418677331084 1/25
1724S85-83 6418677331121 Surface mounting frame, Impressivo, 85 mm, h=40 mm, 2-gang, 1/25
aluminum

Surface mounting frame, Impressivo, 85 mm, h=40 mm, 3-gang,
aluminum

Surface mounting frame, Impressivo, 85 mm, h=40 mm, 4-gang,
aluminum
