IMPRESSIVO® 35

Surface mounting cover frames 100 mm, IP21/IP44
Surface mounting cover frames for 2-gang devices, such as double socket outlets. Also 1-gang devices can be
installed using the adaptor 2519-xx. Suitable for both horizontal and vertical installation. To be used with surface
mounting box 2456.26. Wires must be installed downwards for IP44 protection class. Final IP class of installation is
defined by the used center plate (IP21/IP44).

Type EAN Description Package
White
1721S100-84 6418677331138 Surface mounting frame, Impressivo, 100 mm, h=40 mm, 1-gang, white 1/50
1722S100-84 6418677331176 Surface mounting frame, Impressivo, 100 mm, h=40 mm, 2-gang, white 1/25
1723S100-84 6418677331213 Surface mounting frame, Impressivo, 100 mm, h=40 mm, 3-gang, white 1/25
1724S100-84 6418677331251 Surface mounting frame, Impressivo, 100 mm, h=40 mm, 4-gang, white 1/20
Anthracite
1721S100-81 6418677331152 Surface mounting frame, Impressivo, 100 mm, h=40 mm, 1-gang, 1/50
6418677331190 anthracite 1/25
1722S100-81 6418677331237 1/25
6418677331275 Surface mounting frame, Impressivo, 100 mm, h=40 mm, 2-gang, 1/20
1723S100-81 anthracite

1724S100-81 Surface mounting frame, Impressivo, 100 mm, h=40 mm, 3-gang,
anthracite
Aluminum
1721S100-83 Surface mounting frame, Impressivo, 100 mm, h=40 mm, 4-gang,
anthracite
1722S100-83
6418677331169 Surface mounting frame, Impressivo, 100 mm, h=40 mm, 1-gang, 1/50
1723S100-83 6418677331206 aluminum 1/25
6418677331244 1/25
1724S100-83 6418677331282 Surface mounting frame, Impressivo, 100 mm, h=40 mm, 2-gang, 1/20
aluminum

Surface mounting frame, Impressivo, 100 mm, h=40 mm, 3-gang,
aluminum

Surface mounting frame, Impressivo, 100 mm, h=40 mm, 4-gang,
aluminum

High surface mounting boxes 80 mm, IP20
Surface mounting boxes for high 1-gang devices, such as dimmers, insert height max. 40 mm. Suitable for both
horizontal and vertical installation. Delivery includes box and cover frame.

Type EAN Description Package
White
1721S80-84 6438199002651 Surface mounting box, Impressivo, 80 mm, h=54 mm 1-gang, white 1/10
1722S80-84 6438199002682 Surface mounting box, Impressivo, 80 mm, h=54 mm 2-gang, white 1/5
1723S80-84 6438199002712 Surface mounting box, Impressivo, 80 mm, h=54 mm 3-gang, white
Anthracite 1/10
1721S80-81
1722S80-81 6438199002637 Surface mounting box, Impressivo, 80 mm, h=54 mm 1-gang, anthracite 1/10
1723S80-81 6438199002668 Surface mounting box, Impressivo, 80 mm, h=54 mm 2-gang, anthracite 1/5
Aluminum 6438199002699 Surface mounting box, Impressivo, 80 mm, h=54 mm 3-gang, anthracite
1721S80-83 1/10
1722S80-83
1723S80-83 6438199002644 Surface mounting box, Impressivo, 80 mm, h=54 mm 1-gang, aluminum 1/10
6438199002675 Surface mounting box, Impressivo, 80 mm, h=54 mm 2-gang, aluminum 1/5
6438199002705 Surface mounting box, Impressivo, 80 mm, h=54 mm 3-gang, aluminum
1/10
