2 SURFACE MOUNTING PRODUCTS FOR RENOVATION JUSSI AND IMPRESSIVO

—
2-gang Schuko socket outlet, IP21

Screwless terminals for each contact of the socket outlet for max 4 rigid wires. No Xt­ erminals. The socket outlet insert has shutters. IP21 when

the wires are installed downwards.

Type EAN Description Package
402EA-84 1 / 10
6438199003283 Socket outlet, Impressivo, Schuko, 2-gang, shuttered, screwless
402EA-81 terminals, white 1 / 10

402EA-83 6438199003290 Socket outlet, Impressivo, Schuko, 2-gang, shuttered, screwless 1 / 10
terminals, anthracite

6438199003306 Socket outlet, Impressivo, Schuko, 2-gang, shuttered,
screwless terminals, aluminum

—
2-gang Schuko socket outlet, surface mounting, IP44

Product includes Schuko socket outlet insert, center plate with lid, surface mountig cover frame and box. The socket outlet insert has shutters

and screwless terminals.

Type EAN Description Package
302ESW8­ 1 1 / 10
6438199003443 Socket outlet, Impressivo IP44, 2-gang Schuko, shuttered,
screwless terminals, branching terminals, anthracite

—
2-gang Schuko outlets with special colour, IP21

Screwless terminals for each contact of the socket outlet for max 4 rigid wires. No Xt­ erminals. The socket outlet insert has shutters. IP21

when the wires are installed downwards. These socket outlets can be used, for instance, in hospitals and offices, when there is a need to limit

socket outlet use to certain applications.

Type EAN Description Package
402EA-02 1 / 10
6438199004723 Socket outlet, Impressivo, Schuko, 2-gang, shuttered, screwless
402EA-03 terminals, red 1 / 10

402EA-05 6438199004730 Socket outlet, Impressivo, Schuko, 2-gang, shuttered, screwless 1 / 10
terminals, orange
402EA-06 1 / 10
6438199004747 Socket outlet, Impressivo, Schuko, 2-gang, shuttered, screwless
terminals, green

6438199004754 Socket outlet, Impressivo, Schuko, 2-gang, shuttered, screwless
terminals, blue

—
2-gang Schuko socket outlet, lath installation, IP21

Schuko 2-gang socket outlet for lath installation. There are screwless terminals for each contact of the socket outlet for max 4 rigid wires. No

Xt­ erminals. The socket outlet insert has shutters.

Type EAN Description Package
402EL-84 1 / 10
6438199003894 Socket outlet, Impressivo, Schuko, 2-gang, shuttered, screwless
402EL-81 terminals, lath installation, white 1 / 10

402EL-83 6438199003900 Socket outlet, Impressivo, Schuko, 2-gang, shuttered, screwless 1 / 10
terminals, lath installation, anthracite

6438199003917 Socket outlet, Impressivo, Schuko, 2-gang, shuttered, screwless
terminals, lath installation, aluminium
