14 SURFACE MOUNTING PRODUCTS FOR RENOVATION JUSSI AND IMPRESSIVO

—
IMPRESSIVO® surface mounting
Switches and push switches IP21

—
1-gang switches

Switch with screwless terminals and lamp possibility. Rocker with clipon fastening. IP21 when wires are installed downwards.

Type       EAN                   Description                                                                                   Package
                                                                                                                                   1 / 10
1-gang 2­way switch                                                                                                                1 / 10
                                                                                                                                   1 / 10
1066A-84   6438199003221 1-gang 2w­ ay switch, 16AX/250V, Impressivo, 2 X­terminals,
                                     white                                                                                         1 / 10
                                                                                                                                   1 / 10
1066A-81   6438199003238 1-gang 2­way switch, 16AX/250V, Impressivo, 2 X­terminals,                                                1 / 10
                                     anthracite

1066A-83   6438199003245 1-gang 2w­ ay switch, 16AX/250V, Impressivo, 2 X­terminals,
                                     aluminum

Intermediate switch

1067A-84   6438199003535 1-gang intermediate switch, 16AX/250V, Impressivo, 2 X­
                                     terminals, white

1067A-81   6438199003542 1-gang intermediate switch, 16AX/250V, Impressivo, 2 X­
                                     terminals, anthracite

1067A-83   6438199003559 1-gang intermediate switch, 16AX/250V, Impressivo, 2 X­
                                     terminals, aluminum

—
2-gang switches

Switch with screwless terminals, no lamp possibility. Rocker with clip­on fastening. IP21 when wires are installed downwards.

Type       EAN                   Description                                                                                   Package
                                                                                                                                   1 / 10
2-gang 1-way switch                                                                                                                1 / 10
                                                                                                                                   1 / 10
1065A-84   6438199003191 2-gang 1w­ ay switch, 16AX/250V, Impressivo, 2 Xt­ erminals, white
                                                                                                                                   1 / 10
1065A-81   6438199003207 2-gang 1­way switch, 16AX/250V, Impressivo, 2 Xt­ erminals,                                               1 / 10
                                     anthracite                                                                                    1 / 10

1065A-83   6438199003214 2-gang 1w­ ay switch, 16AX/250V, Impressivo, 2 Xt­ erminals,
                                     aluminum

2-gang 2-way switch

10666A-84  6438199003504 2-gang 2­way switch, 16AX/250V, Impressivo, 2 Xt­ erminals,
                                     white

10666A-81  6438199003511 2-gang 2w­ ay switch, 16AX/250V, Impressivo, 2 Xt­ erminals,
                                     anthracite

10666A-83  6438199003528 2-gang 2­way switch, 16AX/250V, Impressivo, 2 X­terminals,
                                     aluminum

—
3-gang switch

Switch with screwless terminals, no lamp possibility. Rocker with clip­on fastening. IP21 when wires are installed downwards.

Type       EAN                   Description                                                                                   Package
10631A-84                                                                                                                          1 / 10
           6438199003566 3-gang 1w­ ay switch, 16AX/250V, Impressivo, 2 X­terminals,
10631A-81                            white                                                                                         1 / 10

10631A-83  6438199003573 3-gang 1w­ ay switch, 16AX/250V, Impressivo, 2 X­terminals,                                               1 / 10
                                     anthracite

           6438199003580 3-gang 1w­ ay switch, 16AX/250V, Impressivo, 2 X­terminals,
                                     aluminum
