11

—
2-gang 1w­ ay switch, IP21

16AX/250V, with screwless terminals, no lamp possibility. Rocker with clipo­ n fastening. IP21 when wires are installed downwards.

Type     EAN            Description                                                                                                 Package
1065A4                                                                                                                              10 / 100
         6418677307461 2-gang 1­way switch, Jussi, 2 X­terminals

—
3-gang 1­way switch, IP21

16AX/250V, with screwless terminals, no lamp possibility. Rocker with clipo­ n fastening. IP21 when wires are installed downwards.

Type     EAN            Description                                                                                                 Package
10631A4                                                                                                                             10 / 100
         6418677307447 3-gang 1­way switch, Jussi, no X­terminals

—
1-gang 2­way push switch, IP21

10A/250V, with screwless terminals, lamp possibility. Push switch includes an opening and closing contact terminal function. Rocker with clipo­ n

fastening. Delivered with clear lens. IP21 when the wires are installed downwards.

Type     EAN            Description                                                                                                 Package
1466AK4  6418677307560                                                                                                              10 / 100
                        1-gang 2w­ ay push switch, Jussi, Nt­ erminal, lens, lamp not
                        included

—
Lamps for switches

Lamps for switches. Lamps can be installed in 1-gang switch inserts that include the signal/­ search light possibility. Lamps can't be installed to 2­

or 3-gang switch inserts.

Type     EAN            Description                                                                                                 Package
8370                                                                                                                                10 / 100
8372     6410021060701 Lamp, 230V/0.4mA, fluorescent, for 1-gang switches                                                           10 / 100
8375                                                                                                                                10 / 100
8376     6410021060725 Lamp, 230V/2mA, fluorescent, for 1-gang switches                                                             10 / 100
8370R                                                                                                                               10 / 100
8375R    6410021060756 Lamp, 24V/22mA, incandescent, for 1-gang switches                                                            10 / 100

         6410021060763 Lamp, 12V/40mA, incandescent, for 1-gang switches

         6438199004860 Lamp, 250V/0.4mA, LED, for 1-gang switches

         6438199004877 Lamp, 52­ 4V/0,5­2,5mA, LED, for 1-gang switches
