Page 41 - ABB_Wiring_Accessories_Impressivo_Jussi_catalog

JUSSI 41

Flush mounting 1-gang 2-way switch, IP21
16AX/250V Switch with screwless terminals and rocker with clip-on fastening. The terminals are for max 2 rigid
wires. Delivered with pilot light and red lens. Flush mounting on a smooth surface IP21.

Type EAN Description Package
1066UK 6410021060138 1-gang 2-way switch, Jussi, N-terminal, red lens, incl. lamp 10/100

Flush mounting 1-gang 2-way push switch, IP21
16A/250V Push switch with screwless terminals and rocker with clip-on fastening. The terminals are for max 2 rigid
wires. Possibility to connect a lamp. Push switch includes an opening and closing contact terminal function.

Type EAN Description Package
1466U 6410021260118 1-gang 2-way push switch, Jussi, N-terminal, lens, lamp not incl. 10/100

Flush mounting 2-gang 1-way push switch, IP21
16A/250V Push switch with screwless terminals and rocker with clip-on fastening. The terminals are for max 2 rigid
wires. No lamp possibility. Flush mounting on a smooth surface IP21.

Type EAN Description Package
1465U 6410021260132 10/100
1465.20 6418677328824 2-gang 1-way push switch, 16 A, Jussi, no X-terminals 10/100

2-gang 1-way push switch insert 16 A/250 V, 2 X-terminals, no lamp
possibility

2-gang push switch for up/down control, IP21
10A/250V Push switch with screwless terminals and rocker with clip-on fastening. The terminals are for max 2 rigid
wires. Use e.g. for controlling opening/closing of blinds and shutters. Not possible to push both buttons at the
same time. Flush mounting on a smooth surface IP21.

Type EAN Description Package
2-gang push switch, Jussi, for up/down control 10/100
2020/4U-101-212 6410021260156

1-gang rockers, IP21
Rockers with screw or clip-on fastening for all 1-gang switches and push switches. Flush mounting on a smooth
surface IP21.

Type EAN Description Package
2506-212 6410021061357 Switch rocker, Jussi, 1-gang, clip-on fastening 20/200
2506-212R 6410021061432 Switch rocker, Jussi, 1-gang, screw fastening 20/200
2520-212 6410021061364 Switch rocker, Jussi, 1-gang, clear lens, clip-on fastening 20/200
2520-212R 6410021061449 Switch rocker, Jussi, 1-gang, clear lens, screw fastening 20/200

2-gang rockers, IP21
Rockers with screw or clip-on fastening for 2-gang switches and push switches. Flush mounting on a smooth surface IP21.

Type EAN Description Package
2505-212 6410021061395 Switch rocker, Jussi, 2-gang, clip-on fastening 20/200
2505-212R 6410021061470 Switch rocker, Jussi, 2-gang, screw fastening 20/200
