44 WIRING ACCESSORIES CATALOG 2019

1-gang socket outlet Schuko with center plate, IP21
16 A/250 V There are screwless terminals for each contact of the socket outlet. The socket outlet insert has shutters.
The terminals are for max 2 rigid wires. No X-terminals. Flush mounting on a smooth surface IP21.

Type EAN Description Package
20EUCKS-212 6410025061315 Socket outlet, Jussi, Schuko, 1-gang, shuttered, screwless terminals 10/100
20EUC2 6418677302060 10/100
Socket outlet, Jussi, Schuko, 1-gang, shuttered, screwless terminals,
23-01EUC-212 6410025061117 claws 10/100

Socket outlet, Jussi, Schuko, 1-gang, shuttered, screw terminals

1-gang Schuko socket outlet with center plate and LED light, IP20
16 A/250 V There are screwless terminals for each contact of the socket outlet. The socket outlet insert has shutters.
The terminals are for max 2 rigid wires. No X-terminals. A white color LED light is integrated into the socket outlet.

Type EAN Description Package
20EUCBLI-214 4011395100738 1/10
Socket outlet, Jussi, Schuko, 1-gang, shuttered, screwless terminals,
LED light

1-gang Schuko socket outlet with center plate and USB charger, IP20
The socket outlet has an integrated USB charger 5 V/0.7 A with electronic short-circuit and overload protection.
Compatible with USB devices, iPod and iPhone. The Schuko socket outlet is 16A/250V. There are screwless terminals
for each contact of the socket outlet. The socket outlet insert has shutters. The terminals are for max 2 rigid wires.
No X-terminals.

Type EAN Description Package
1
20EUCBUSB-214 4011395164532 1-gang Socket outlet and USB charger, Jussi, shuttered Schuko,
screwless terminals

Residual current devices
16 A/250 V IP21, with built-in A-type residual current device (RCD), tripping current 30 mA. Approved for extending a
branch circuit, but only regular sockets connected to protected outlet wires are protected. The socket outlet insert
has shutters. The products are sold with cover plates. The socket outlet insert has shutters and screwless terminals.

Type EAN Description Package
3120EUC-214 7612271473822 1-gang, 30 mA, type A 1/10
3150UC-214.1 7612271473846 RCD (30 mA), extendable 1/10

Non-earthed socket outlet with center plate
16A/250V There are screwless terminals for each contact of the socket outlet. The socket outlet insert has shutters.
The terminals are for max 2 rigid wires. No X-terminals. Can only be installed in dry indoor spaces.

Type EAN Description Package
23-01UC-212 6410025060110
Socket outlet, Jussi, non-earthed, 1-gang, shuttered, screw terminals 10/100
