JUSSI 49

Speaker outlet, mono
There is one red and one black gold plated terminal screw for the speaker wires and screw terminals for max 10 mm²
internal wires.

Type EAN Description Package
1819.LSP 6418677334337 Speaker insert, with terminal screws 1/10
1819-214 6418677334344 Center plate, Jussi, speaker/RJ45, for inserts 1819.xx/1819.LSP 1/10

Tele outlet 6,3 mm Jack
Stereo Plug Terminal for 6,3 mm Jack Plug. It can be used in calling and alarm systems as a socket outlet, or as a
headphone or loudspeaker terminal. Good marking possibilities.

Type EAN Description Package
FOT3103 1/10
6410070608633 Stereo Plug Terminal for 6,3 mm Jack Plug

Fixing frame and center plate for D-sub
Fixing frame and center plate for 25-pole D-connector. With adapter plate for 9 -and 15-pole D-connectors. Delivered
without terminal.

Type EAN Description Package
2549 6410070602815 Tele outlet, Jussi, 25pin D-connector, connector not included 1/10
PEL15 6410070602952 Adapter plate for 9/15pin D-connector
10/200

Fixing frame and center plate for XLR-connectors
Fixing frame and center plate for XLR / FP-serie connector. The connector is not included.

Type EAN Description Package
2553-214 10
6410070602785 Tele outlet, Jussi, XLR audio connector, connector not included

Fixing frame and center plate, Ø 22,5 mm
Fixing frame and center plate for devices assembled into 22,5 mm hole.

Type EAN Description Package
2533-214 10
6410070602860 Tele outlet, Jussi, 22,5 mm hole

Equipotential outlet 2-gang
Equipotential outlet 2-gang. Screw terminals for 1 x 6 mm² and 4 x 2,5 mm² wires. The product includes insert and
center plate.

Type EAN Description Package
2095UC-212 10/100
6410070602907 Equipotential outlet, Jussi, 2-gang

Fixing frame and center plate, Ø 19 mm
Fixing frame and center plate for devices assembled into 19 mm hole. E.g. for installation of potential compensation
plug 70 602 91 or TWINAX connectors.

Type EAN Description Package
2534-212 10
6410070602853 Tele outlet, Jussi, 19 mm hole

Equipotential outlet 1-gang, Ø 19 mm
Equipotential connector for internal cabling up to 6 mm². Connection by soldering or pressing with tool. Fits to the
center plate 2534-212.

Type EAN Description Package
0471.00037 6410070602914 Equipotential outlet, 1-gang connector for 2534-212 10/100
