52 WIRING ACCESSORIES CATALOG 2019

—
Jussi surface mounting IP20/IP21
Surface mounting boxes and accessories

Floor installation housing
Product is usually mounted on the wall by the floor. When installing dimmers, the bottom of the housing need to be
opened and further space is needed behind, a.g. flush mounting box. The lower part of the device housing can be
used as a junction box, max 5 terminals.

Type EAN Description Package
2511L 6438199004907 Surface mounting box, Jussi, 85 mm, 1-gang, lath installation, white 1/10
2551L-212 6410014027513 Floor installation box, Jussi, for 1-gang devices 5/50
2552L-212 6410014027520 Floor installation box, Jussi, for 2-gang socket outlets 5/50

Corner box 85 mm
Surface mounting box for 2 devices, also for electronic devices. Horizontal or vertical installation in corners. Use with
85 mm 2-gang cover frame (2512).

Type EAN Description Package
2512H 6438199000602
2512H.13 6438199000671 Surface mounting box, Jussi, corner installation, 85 mm, 2-gang 1/20

Surface mounting box, Jussi, corner installation, 85 mm, 2-gang, with 1/20
cover frame

Surface mounting frames 85 mm
Frame height 22 mm. Use with 85 mm cover frames.

Type EAN Description Package
2511R-212 6410025161749
Surface mounting frame, Jussi, 1-gang for 1-gang device, for 85 mm 10/100
2552R-212 6410025161725 cover plates, h=22

2513R-214 6438199001999 Surface mounting frame, Jussi, 2-gang for 1-gang devices, for 85 mm 10/100
cover plates, h=22

Surface mounting frame, Jussi, 3-gang for 1-gang devices, h=22 1/5

Surface mounting frames 100 mm
Frame height 25 mm. Use with 100 mm cover frames.

Type EAN Description Package
2521R-100 6418677328510 Surface mounting frame, Jussi, for one double socket outlet, h=25 10/100
2522R-100 6418677331404
2523R-100 6418677331411 Surface mounting frame, Jussi, for two double socket outlets, h=25 10/100

Surface mounting frame, Jussi, for three double socket outlets, h=25 1/5

Surface mounting frame for double socket outlets
Frame height 22 mm. Use with double socket outlets 302EUJ.1 and 232EUJ.

Type EAN Description Package
2551R-212 6410025161510
Surface mounting frame, Jussi, for one double socket outlet 302EUJ.1 10/100
or 232EUJ

Surface mounting frames
Frame height 36 mm. Use with 85 mm cover frames. One X-terminal included.

Type EAN Description Package
2551-510-212 6410024065710
2552-510-212 6410024065727 Surface mounting frame, Jussi, 1-gang, for 85 mm cover plates, h=36 10/100

Surface mounting frame, Jussi, 2-gang, for 85 mm cover plates, h=36 5/50
