JUSSI 57

Socket outlet with residual current device, IP44
230 V, 16 A, IP44, with A-type built-in residual current device (RCD), tripping current 30 mA. The socket outlet insert
has shutters. Approved for extending a branch circuit, but only regular sockets connected to protected outlet wires
are protected. Do not use the cellular-plastic seal in surface mounting.

Type EAN Description Package
3120EUG-44.2 7612271473860 1/10
3120EUG-44 7612271473884 Socket residual current device, 30 mA, A-type 1/10

Socket outlet, IP44, Schuko, 1-gang with RCD (30 mA), shuttered,
extendable, flush mounting

Cable entry
Thermoplastic cable entries for Jussi IP44/IP55 surface mounting products. Cable entry can be used for fitting 2
accessories.

Type EAN Description Package
2124SW 6418677335884 Cable entry for Jussi IP44/IP55 products, 1-way 5/50
2125SW 6418677335891
2138SW 6418677334610 Cable entry for Jussi IP44/IP55 products, 2-way 5/50
1237SW 6418677335952
Cable entry for fitting Jussi IP44/IP55 products 5/50

Cable entry to the bottom for Jussi IP44/IP55 products, 1-way, round 5/50
16,5 mm
