62 WIRING ACCESSORIES CATALOG 2019

—
Dimmers

Flat LED-dimmer, with rotary control
Rotary control dimmer for LED lamps. Via mode switch adjustable between leading edge control (RL) or trailing edge
control (RC). 2-wire connection (N-wire not needed). Nominal power: 2-100 VA or 10-400W(details in manual).
Linear and low-noise operation. Mixed loads allowed. Electronic short-circuit and overload protection. Adjustable
minimum brightness. Also applicable for 1-gang 2-way installations. Nominal voltage 230 V/50-60 Hz. Maximum 20
LED lamps behind one dimmer. Compatibility with defined Philips LED lamps is guaranteed.

Note!
There might be limitations from transformer producers on how many dimmable LED bulbs can be connected behind
one transformer.

Type EAN Description Package
LED dimmer, rotary 2-100 VA, with neon lamp, Jussi 1/10
6523URJGL-214-103 4011395232118 LED dimmer, rotary 2-100 VA, with neon lamp, Impressivo 1/10
LED dimmer, rotary 2-100 VA, insert with neon lamp 1/10
6523URCGL-84-103 4011395232125 Dimmer center plate, neon lamp included, white 1/10
Dimmer center plate, neon lamp included, aluminium 1/10
6523UR-103-500 4011395232101 Dimmer center plate, neon lamp included, anthracite 1/10

6540-84-102-510 4011395265789 Dimmer center plate, neon lamp included, steel 1/10
Dimmer center plate, neon lamp included, white matt 1/10
6540-83-102-510 4011395265772 Dimmer center plate, neon lamp included, black matt 1/10

6540-81-102-510 4011395265765

Design series. Delivery time to ask.

6540-866-102 4011395125496

6540-884-102 4011395129425

6540-885-102 4011395129487

LED-dimmer, with rotary control
Rotary control dimmer for LED lamps. Via mode switch adjustable between leading edge control (RL) or trailing edge
control (RC). 2-wire connection (N-wire not needed). Nominal power: 2-100 W/VA (retrofit LED loads).
Nominal power: 10 - 250 W/VA (non-LED loads). Linear and low-noise operation. Mixed loads allowed. Electronic
short-circuit and overload protection. Adjustable minimum brightness. Also applicable for 1-gang 2-way
installations. Nominal voltage 230 V/50-60 Hz. Maximum 20 LED lamps behind one dimmer. Compatibility with
defined Philips LED lamps is guaranteed.

Note!
There might be limitations from transformer producers on how many dimmable LED bulbs can be connected behind
one transformer.

Type EAN Description Package

Impressivo (incl. insert and center plate) 1/10
1/20
6523U-102-500 4011395151310 LED dimmer insert, rotary 2-100 VA 1/10
1/10
2117C-214 6438199003887 Center plate, rotary button and nut 1/10

6540-84-102-510 4011395265789 1/10
1/10
6540-83-102-510 4011395265772 Impressivo, with rotary knob, with indication lamp 1/10

6540-81-102-510 4011395265765 Dimmer center plate, Impressivo, anthracite, with neon lamp

Design series. Delivery time to ask.

6540-866-102 4011395125496 Dimmer center plate, neon lamp included, steel

6540-884-102 4011395129425 Dimmer center plate, neon lamp included, white matt

6540-885-102 4011395129487 Dimmer center plate, neon lamp included, black matt
