JUSSI 47

DKS-adapter with Speakon connector
Suitable for DKS-center plate 1758-214. Speakon 4 pin audio connector is included.

Type EAN Description Package
1876EB.SPE 1/10
6418677334368 Tele outlet for DKS-system with Speakon audio connector

DKS-adapters
Different adapters for DKS-system. Suitable for DKS-center plate 1758-xx.

Type EAN Description Package
RJ45
1867EB 4011395182802 Adapter for DKS-system, 2 x RJ45, Keystone 10/100
1875EB 4011395776902 Adapter for DKS-system, 2 x RJ45, AMP 10/100
1872EB 4011395540800 Adapter for DKS-system, 2 x RJ45, Systimax 10/100
Fiber
1870EB 4011395454107 Adapter for DKS-system, fiber 2 x Simplex ST 10/100
1874EB 4011395734902 Adapter for DKS-system, fiber 2 x SCD 10/100
Audio
1853EB 4011395181409 Adapter for DKS-system, XLR audio connector type FP 10/100
1854EB 4011395181508 Adapter for DKS-system, XLR audio connector type MP 10/100
1876EB 4011395022566 Adapter for DKS-system, XLR D-type or Speakon audio connector 10/100
Others
1850EB 6438100605308 Adapter for DKS-system, D-type 9-pin connector 10/100
1855EB 4011395181607 Adapter for DKS-system, 2 x BNC/TNC, 9,8 mm 10/100
1857EB 6418677329975 Adapter for DKS-system, 2 x BNC/TNC, 12,9 mm 10/100
1869EB 4011395183007 Adapter for DKS-system, blank 10/100

USB charger
For supply and support of two mobile devices via USB-cable. With two USB A-type connectors. With electronic short-
circuit and overload protection. Rated voltage: 230 V~/5 V-, 50 Hz - 60 Hz, power dissipation 0.3W. Suitable for: In
case one output is used rated current max 1400 mA. In case two output are used rated current max 700 mA.

Type EAN Description Package
Tele outlet insert, USB charging station 2 x 0.7 A 1
Insert: Delivery time 3 weeks Center plate, Jussi, for tele outlet
1/10
6472U 4011395151594

Center plate

2539-214 6418677331343

Tele outlet USB
Tele outlet with USB A-type connector. Compatible up to USB 2.0 versions. Internal connections with screw type
terminals.

Type EAN Description Package
Tele outlet insert, with USB A-type connector 1
Insert: Delivery time 3 weeks Center plate, Jussi, for tele outlet
1/10
0261/13 4011395167557

Center plate

2539-214 6418677331343

Tele outlet VGA
Tele outlet for VGA display with D-sub 15pin connector. Internal connections with screw type terminals.

Type EAN Description Package
Tele outlet insert, with VGA 15pin D-sub connector 1
Insert: Delivery time 3 weeks Center plate, Jussi, for tele outlet
1/10
0261/23 4011395167618

Center plate

2539-214 6418677331343
