42 WIRING ACCESSORIES CATALOG 2019

Signal lights

Lamps for switches
Lamps for switches and push buttons. Lamps can be installed in 1-gang switch inserts that include the signal-/
search light possibility. Lamps can't be installed in 2- or 3-gang switch inserts.

Type EAN Description Package
8370 6410021060701 Lamp, 230 V/0.4 mA, fluorescent, for 1-gang switches 10/100
8372 6410021060725 Lamp, 230 V/2 mA, fluorescent, for 1-gang switches 10/100
8375 6410021060756 Lamp, 24 V/22 mA, incandescent, for 1-gang switches 10/100
8376 6410021060763 Lamp, 12 V/40 mA, incandescent, for 1-gang switches 10/100
8370R 6438199004860 Lamp, 250 V/0.4 mA, LED, for 1-gang switches 10/100
8375R 6438199004877 Lamp, 5-24 V/0.5-2.5 mA, LED, for 1-gang switches 10/100

Rocker lens with symbols
Rocker lens with symbols for 1-gang Jussi-rockers with lens.

Type EAN Description Package
2145TR 4011395077108 Rocker lens, Jussi, clear, "key" symbol 100
2145KI 6410020464821 Rocker lens, Jussi, clear, "bell" symbol 100

Signal light fittings
250V/max 3W, E-10 lamp, screw terminals. Cap with clip-on fastening is included. Lamp 8340 is not included. Can
only be installed in dry indoor spaces (IP20).

Type EAN Description Package
2661U-11 6410021460181 Signal light, Jussi, E10/3W max, clear 10/100
2661U-12 6410021460167 Signal light, Jussi, E10/3W max, red 10/100
2661U-13 6410021460150 Signal light, Jussi, E10/3W max, green 10/100
2661U-14 6410021460198 Signal light, Jussi, E10/3W max, orange 10/100
8340 6410021460891 Lamp, 230 V/3W/E10, incandescent, for signal light fittings
100/1000

Socket outlets

Euro socket outlet with center plate, IP21
2,5A/250V There are screwless N and L terminals for max 4 wires and 2 screwless X-terminals for max 2 wires. The
socket outlet insert has shutters. The terminals are for rigid wires. Flush mounting on a smooth surface IP21.

Type EAN Description Package
303UC 6418677335136 10/100
Socket outlet, Jussi, Euro, 3-gang, shuttered, screwless terminals,
branching terminals, 2 X-terminals

2-gang socket outlet Schuko with cover plate, screwless terminals, IP21
16A/250V. There are screwless terminals for each contact of the socket outlet for max 4 rigid wires. No X-terminals.
The socket outlet insert has shutters. Flush mounting on a smooth surface IP21.

Type EAN Description Package
302EUJ 6418677310409 10/100
Socket outlet, Jussi, Schuko, 2-gang, shuttered, screwless terminals,
302EUJ.CLAW 6418677311628 branching terminals 10/100

Socket outlet, Jussi, Schuko, 2-gang, shuttered, screwless terminals,
branching terminals, claws
