E lectronic 69

iNetRadio
WLAN Internet radio with display for flush-mounted installation. For the reception of national and international
radio stations via Internet. Radio station search possible via various genres. Integrated web-server for configuration
and control. Remote operation with smartphone via browser surface. UPnP replay function. It is controlled via
smartphone. For mono/stereo operation. 8 radio stations storable.

Type EAN Description Package

IMPRESSIVO set Design series. Delivery time to ask. 1/10

8240-84-500 4011395157251 iNetRadio kit 1/10
1/10
Design series. Delivery time to ask. 1/10
1/10
8216U-500 4011395157220 iNetRadio 1/10

8252-214 4011395104521 DigitalRadio, center plate, Jussi

8252-84 4011395104569 DigitalRadio, center plate, Impressivo, white

8252-81 4011395104538 DigitalRadio, center plate, Impressivo, anthracite

8252-83 4011395104552 DigitalRadio, center plate, Impressivo, aluminum

—
Timers

Countdown timer
User friendly timer with fixed time settings 15 min, 30 min, 1h, 2h, 4h or 8h. Countdown time is set with a
screwdriver. 2-pole switch.

Type EAN Description Package

Jussi (incl. insert and center plate) 1/10

T210-214 6438199002231 Basic timer, Jussi 1/10
1/10
Impressivo (incl. insert and center plate) 1/10

T210-84 6438199002248 Basic timer, Impressivo, white

T210-81 6438199002255 Basic timer, Impressivo, anthracite

T210-83 6438199002262 Basic timer, Impressivo, aluminum

Timer kits
Timer kits include Jussi-timer, single schuko socket outlet and installation frame or box.
Fixed time options: 15 min, 30 min, 1h, 2h, 4h and 8h. Exchangeable labels with the time options to mark center plate
with selected time. 230 VAC, 50Hz, 0 - 40C, IP21, 2-pole wiring. 10A resistiv load (2300 W), 2AX-load (e.g. fluorescent
lamp). Screw terminals max 2,5 mm2. Signal light when active.

Type EAN Description Package
T210-20EUCKS-214 6438199003429 Timer set frame, Jussi 1/10
T210-20EUCKS-214.H 6438199003412 Timer set corner box Jussi 1/10

Timer switches
Timer switch display, 10 A. Four switching times per day can be user-defined for each day of the week. Automatic
summer/wintertime switch-over. 14-hour power reserve. Nominal voltage: 230 V/50 Hz. Operating temperature
range: 0 °C - 35 °C. Timer switch insert is connected to universal relay unit 6401U-102. Suitable center plates 6435-8X.

Type EAN Description Package
Inserts
Universal relay unit insert, 10 A. 1/10
6401U-102 4011395991299 Timer switch display 1/10

6455-101-500 4011395186657 Center plate for timer switch, Jussi 1/10
Timer switch, center plate, Impressivo, white 1/10
Centre plates Timer switch, center plate, Impressivo, aluminum 1/10

6435-214 4011395071656 Timer switch, center plate, painted steel 1/10
Timer switch, center plate, white matt 1
6435-84 4011395071854 Timer switch, center plate, black matt 1

6435-83 4011395071922

Design series. Delivery time to ask.

6435-866 4011395086919

6435-884 4011395148013

6435-885 4011395148020
