Flex Pipes

INOX (L<1000 mm) OD
ID
Dinex no. L mm OD mm ID mm ID Inch
L - compressed length
87151 410 55,0 51,0 2

94502 250 62,0 58,0 2 1/4

87139 450 65,0 61,0 2 3/8

87164 450 68,0 64,0 2 1/2

50163 250 74,0 70,0 2 3/4

80220 357 81,0 77,0 3

87176 450 81,0 77,0 3 L

95124 200 94,0 90,0 3 1/2

80641 210 94,0 90,0 3 1/2

80513 275 94,0 90,0 3 1/2

80157 398 94,0 90,0 3 1/2

80155 419 94,0 90,0 3 1/2

87189 450 94,0 90,0 3 1/2

49176 285 105,0 101,0 3 7/8

49199 375 105,0 101,0 3 7/8

81128 255 107,0 103,0 4

64220 275 107,0 103,0 4

87102 457 107,0 103,0 4

80183 580 107,0 103,0 4

94500 550 107,0 103,0 4

49133 337 115,0 111,0 4 3/8

68217 281 119,0 115,0 4 1/2

81224 327 119,0 115,0 4 1/2

81191 316 119,0 115,0 4 1/2

80131 400 119,0 115,0 4 1/2

95194 440 119,0 115,0 4 1/2

87114 450 119,0 115,0 4 1/2

80655 500 119,0 115,0 4 1/2

49247 409 125,5 121,5 4 3/4

80768 143 132,0 128,0 5

81133 300 132,0 128,0 5

94501 550 132,0 128,0 5

Flex Pipes with Joints

Dinex no. A-end B-end Length

Type Diameter Type Diameter

53162 Plain OD 71,5 Slitted ID 77,0 365

51290 Plain OD 88,9 Slitted ID 90,5 365

52176 Slitted ID 76,0 Slitted ID 72,5 365

47194 Plain OD 110,0 Flex ID 111,0 415

47183 Plain OD 110,0 Flex ID 111,0 375 Flex Plain Slitted
