Kiln & Accessories

Filter Cleaning Kiln

Dinex no. Description
43060 By heating up the core of the filter using hot air, the kiln will automatically burn trapped soot and
blow the filter clean in the meantime. Ashes will be trapped in a separate container for easy and
environmentally correct disposal. No air intake installation is required – only power supply,
pressurized air, and output into the open as the air is cooled down and filtered before being expelled.

* Fix plate no. 43062 ( 1 pcs.) is delivered with the DiCLEAN® klin

Dimensions Dimensions Weight Power supply Pressurized air

Kiln (W x D x H) Kiln room

1500 x 750 x 2100 Filters up to Ø 17,7" 310 kg 3 x400V+N+PE 12,5 kW 7 bar

Cordierite filters SiC filters

Cycle time Power Usage Cycle time Power Usage

2 hrs. 15 min. 21 kW/cycle 2 hrs. 50 min. 29 kW/cycle

For further information please require our brochure and installation manual

Kiln Accessories Fix Plate

Dinex no. Description
43065 Fix plate B203 (7,5")
43061 Fix plate B246 + B281 (9" + 10,5")
43062 Fix plate B297 + B 317 (11,25 + 12")
43063 Fix plate B397 (15")

Other fix plate sizes on request

Filter Test Machines

Dinex no. Description

43068 DiCLEAN® DPF test machine T401
