Special Modules ØD ØD2
L4
Lambda Larsen® connection L3
L2
L

Pre-Cat Modules / Special Pre-Cat

Dinex no. Ø mm L mm Filter Filter type Type L2 mm Dim Ø mm Side cut Off-center

size inch mm Dim. mm Dim. mm

(D2) (L3) (L4)

980662* 203 270,0 7,5x4,0 Pr e-cat modu le Cen ter 60 ID 71,0

981552 203 243,0 7,5x4,0 Pr e-cat

980783* 246 343,5 9,0x4,0 Pr e-cat modu le Cen ter 80 ID 77,0

985201* 246 388,0 9,0x4,0 Pr e-cat modu le Off -cent er 80 ID 90,5 55,0

980521* 281 300,0 10,5x4,0 Pr e-cat modu le Off -cent er 60 ID 81,0 45/48

980691* 281 420,0 10,5x4,0 Pr e-cat modu le Cen ter 80 ID 102,5

981951 281 343,0 10,5x4,0 Pr e-cat

981243 281 120,0 10,5x4,0 Pr e-cat

985285 281 370,0 10,5x4,0 Pr e-cat

985314* 281 370,0 10,5x4,0 Pr e-cat modu le Off -cent er 80 ID 90,0 75,0

980576* 297 230,0 11,25x4,0 P re-ca t mo dule Off-c enter 85 ID 90,0 54,5

980613 297 350,0 11,25x4,0 P re-ca t mo dule Cente r 75 ID 111,0

981220 297 131,0 11,25x4,0 Pr e-cat

980867 317 125,0 11,25x4,0 Pr e-cat

981414 397 122,0 11,25x4,0 Pr e-cat

980667 397 295,0 11,25x4,0 Pr e-cat modu le Sid e in/ out 26 9 OD 114,3 210,0

980640* 445 339,0 11,25x4,0 Pr e-cat mod ule S ide in /out 269 OD 114,3 254,5

* pop-nuts for temp./BP

Side Modules with Flange D2
L3
Dinex no. Ø mm L mm Spec. Flange type Type L2 mm Dim Ø Side cut
D
mm Dim. mm
L
(D2) (L3) L2

981998* 203 100 Fl ange Squa red Side in/ou t 127 OD 50,0 52,5

981985* 203 100 Fl ange Squa red Side in/ou t 141 OD 57,0 52,5

981196* 246 170 Fl ange Squa red Side in/ou t 175 OD 88,9 85,0

981259* 246 170 Fl ange/ Opac ity Squa red Side in/ou t 175 OD 88,9 85,0

980515* 297 255 Fl ange Roun d Side in/ou t 195 OD 101,6 170,0

980796 297 190 Fl ange Squa red Side in/ou t 215 OD 101,6 110,0

* pop-nuts for temp./BP

78
