COVERS 69

Surface installation adapter
Surface mounting of a lamp outlet is done with the AKL2 adapter (extension ring). The height of the ring is 11 mm.
Designed to fit AKK13J, AK20.1 and AK1.1. Made of halogen free material (IEC/61249-2-21).

Type EAN Description Package
AKL2 6410011525302 Surface mounting ring for AKKJ13 / 20.1 / 1.1 10/100

Ceiling rose cover, bipolar
Celining rose cover, flush mounting. For installation in ceiling rose with a hook in the middle. Screwless connection.
Delivered with a hook. Made of halogen free material (IEC/61249-2-21).

Type EAN Description Package
AKI38 6418677305269 Lighting socket outlet TL 21/75 10/100

Lamp outlets, wall mounting
Lamp outlet for walls, 6 A, 250 V. AKK4 lamp outlet can be outlet in standard wall mounting box and AKK5 for
junction- or mounting box.

Type EAN Description Package
AKK4 6418677305238 Lighting socket outlet 85x85 mm 20/200
AKK5 6418677305245 Lighting socket outlet 100x100 mm 10/100

Mounting box cover
Made of halogen free material (IEC/61249-2-21).

Type EAN Description Package
AKI1 6418677300837 Box cover KDL 50/200
AKI2 6418677300851 BOX COVER KFL 20/200
AKI7 6418677301117 Box cover STL60 50/500

Mounting box cover with inlet for insulated cable

Type EAN Description Package
AKI3 6418677300868 BOX COVER KDL-U 20/200
AKI4 6418677300875 BOX COVER KFL-U 20/200
AKI8 6418677301124 Box cover STL-U60 20/200

Ceiling rose cover
Made of halogen free material (IEC/61249-2-21).

Type EAN Description Package
AKI35 6418677301414 Ceiling rose cover 10/100

Hooks for ceiling roses

Type EAN Description Package
ATR15 6418677301421 Hook 38 mm 100/1000
ATR16 6418677301438 Hook 45 mm 100/1000
ATR17 6418677301445 Hook 75 mm 100/1000

Cover EAN Description Package
6418677307751 Cover 38 mm 50/1500
Type
AKI37
