Conduit end piece
A plug is supplied with each conduit end piece. The AJ5.16 conduit end piece is primarily used for the termination of
plastic conduits in concrete casting. After casting, the conduit end piece is cut to the desired length at one of the
cut-off grooves, and the trunking is continued with a conduit of the same size. The plug protects the conduit from
dirt, concrete and foreign particles. Made of halogen free material (IEC/61249-2-21).

Type EAN Description Package
AJ5.16 6410011301661 Ø16 mm 25/250
AJ5.20 6410011301708 Ø20 mm 25/250

Pre-bent 90° conduit bends with sleeve in long end
Pre-bent curve conduit extensions with a 90° angle and small radius are used alongside the conduit end pieces
AJ5.20, JMKL25.11 and JMKL32.11, the bushing insulators AJ5.20, AJI13, AJI14 and AJI15 and the mounting and
junction boxes in concrete casting. Curve conduit extensions are equipped with a sleeve for continuing the conduit
from the product's long end.

Type EAN Description Package
JMKL16.4 6418677300370 Ø16 mm, 90° 20/200
JMKL16.5 6418677300387 Ø16 mm, 90° 20/100
JMKL16.6 6418677300394 Ø16 mm, 90°
JMKL16.8 6418677300431 Ø16 mm, 90° 100/200
JMKL20.3 6418677300400 Ø20 mm, 90° 20/200
JMKL20.4 6418677300424 Ø20 mm, 90° 20/100
JMKL20.5 6418677300448 Ø20 mm, 90° 20/100
JMKL25.2 6418677300455 Ø25 mm, 90° 20/200
JMKL32.2 6418677300462 Ø32 mm, 90° 20/100
JMKL40.1 6418677300479 Ø40 mm, 90° 20/100
JMKL50.1 6418677300486 Ø50 mm, 90° 10/50
10/50

Bushing insulators
This conduit end piece is used for the termination of plastic conduits in concrete casting. The end piece is cut to the
desired length after casting. The trunking is continued with a conduit of the same size. The plug prevents the casting
from entering the conduit. It is easy to extend trunking from the end pieces with the pre-bent curve conduit extensions.

Type EAN Description Package
JMKL16.11 6418677300493 Ø16 mm, 750N 100/400
JMKL20.11 6418677300509 Ø20 mm, 750N
JMKL25.11 6418677300516 Ø25 mm, sleeve on the plugged end, 750N 20/200
JMKL32.11 6418677300523 Ø32 mm, sleeve on the plugged end, 750N 20/100
JMKL16.12 6418677300547 Ø16 mm, 750N 20/100
JMKL20.12 6418677300554 Ø20 mm, 750N 100/400
JMKL25.12 6418677300561 Ø25 mm, sleeve on both ends, 750N 20/200
JMKL16.13 6418677300578 Ø16 mm, 750N 20/100
JMKL20.13 6418677300585 Ø20 mm, 750N 20/200
20/200

Conduit sealing plug
End plug for Ø16, Ø20 and Ø25 mm conduits. Made of halogen free material (IEC/61249-2-21).

Type EAN Description Package
PMR38 6410011310915 For Ø16 / 20 / 25 mm conduits 100/1000

Conduit sleeve
Conical cable protection. Pushed into the end of a (metallic) conduit to protect the cable. Thermoplastic.

Type EAN Description Package
ATI38 6418677300639 Conduit cover for 16 mm pipe 100/1000
ATI39 6418677300646 Conduit cover for 20 mm pipe 100/1000
ATI40 6418677300653 Conduit cover for 25 mm pipe 100/1000
ATI41 6418677300660 Conduit cover for 32 mm pipe 100/1000
ATI42 6418677308291 Conduit cover for 40 mm pipe
ATI43 6418677308307 Conduit cover for 50 mm pipe 50/500
50/500
