Piping materials


Conduit extensions
The purpose of conduit extensions, curve conduit extensions, bushing insulators and other accessories, e.g. inlets,
is to extend installation pipes and to make it easier to attach them to mounting and junction boxes.Use of ready-
made curve conduit extensions saves in installation costs; furthermore, the curves do not open when a bent conduit
straightens out.Bushing insulators make it possible to add an installation pipe to a concreting mould e.g. during
vaulting masonry of a building. Made of halogen free material (IEC/61249-2-21).

Type EAN Description Package
AJI6 6418677300110 Ø16 mm, 90° 100/200
AJI7 6418677300127 2 x Ø16 mm, 90°
AJI9 6418677300141 4 x Ø16 mm, 90° 50/100
AJI10 6418677300158 Ø20 mm, 90° 50/100
AJI11 6418677300165 2 x Ø20 mm, 90° 50/100
AJI12 6418677300172 Ø25 mm, 90° 20/100
AJI13 6418677300189 Ø32 mm, 90° 20/100
AJI14 6418677300196 Ø40 mm, 90° 20/100
AJI15 6418677300202 Ø50 mm, 90° 20/100
20/100

Bushing insulators 45 degrees
Bushing insulators are designed for feedthrough situations of electrical conduits in concrete structures. They
are also used for connecting conduits in concrete slabs (floors) to conduits in hollow walls. Made of halogen free
material (IEC/61249-2-21).

Type EAN Description Package
AJI52 6418677300301 Ø16 mm, 45° 50/200
AJI53 6418677300318 Ø20 mm, 45° 20/100
AJI54 6418677300325 Ø25 mm, 45° 20/100
AJI55 6418677300332 Ø32 mm, 45° 20/100

Bushing insulators 45 degrees
Bushing insulators are designed for feedthrough situations of electrical conduits in concrete structures. They
are also used for connecting conduits in concrete slabs (floors) to conduits in hollow walls. Made of halogen free
material (IEC/61249-2-21).

Type EAN Description Package
AJI60 6418677300257 Ø16 mm 50/200
AJI61 6418677300264 Ø20 mm 50/200
AJI62 6418677300271 Ø25 mm 20/100
AJI63 6418677300288 Ø32 mm 20/100

Conduit extensions, type BAM

Type EAN Description Package
AJI18 6418677300592 2 x Ø16 mm 20/100
AJI19 6418677300608 Cover for AJI18 50/500
