Vertical Outlet Pipe Systems

A
L

100

600

Ø
400

Systems with Heat Shield 800 mm - ZINC

System Ø L mm Heat shield A mm Tail Pipe Bend Clamp Cross bar

Dinex no. Dinex no. Dinex no. Dinex no. Dinex no. Dinex no.

95611 80 1500 95582 800 91681 91680 99780 95502

95612 80 2000 95582 800 91682 91680 99780 95502

95613 80 2250 95582 800 91683 91680 99780 95502

95602 90 1500 95589 800 91691 91690 99789 95502

95603 90 2000 95589 800 91692 91690 99789 95502

95604 90 2250 95589 800 91693 91690 99789 95502

95608 100 1500 95503 800 91601 91600 99700 95502

95609 100 2000 95503 800 91602 91600 99700 95502

95610 100 2250 95503 800 91603 91600 99700 95502

95605 120 1500 95521 800 91621 91620 99720 95502

95606 120 2000 95521 800 91622 91620 99720 95502

95607 120 2250 95521 800 91623 91620 99720 95502

95617 130 2250 95522 800 91624 91625 99730 95502

Systems with Heat Shield 1000 mm - INOX

System Ø L mm Heat shield Clamp A mm Tail Pipe Bend Clamp Cross bar

Dinex no. Dinex no. Dinex no. Dinex no. Dinex no. Dinex no. Dinex no.

95615 101,6 2000 95532 95802 1000 91604 91605 99702 9 5502

95616 127,0 2000 95627 95827 1000 91627 91628 99702 95502
